xHT100 / 4" Thermal Transfer Label Printer — Product Overview & Specifications
Technical Specifications
-
Model Name / Number: HT100 / 4" Thermal Transfer Label Printer
-
Printing Method: Direct Thermal / Thermal Transfer
-
Resolution: 203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
-
Printing Speed: 2 ips ~ 5 ips (at 203 dpi) / 2 ips ~ 4 ips (at 300 dpi)
-
Printing Width: 20 mm ~ 108 mm (203 dpi) / 20 mm ~ 106 mm (300 dpi)
-
Programming Language: TSPL, ZPL
-
Printing Length: 15 mm ~ 1200 mm
-
Interface Standard: USB Type-B, Serial Port, Ethernet (Ethernet Cable included)
Barcode Support
-
Linear Barcodes: Code 39, Code 93, Code 128UCC, Code 128, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, UCC/EAN-128, UPC-A, UPC-E, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11
-
2D Barcodes: QR Code, PDF417, Data Matrix, Aztec
Media & Ribbon Specifications
-
Media Type: Roll-fed or Fan-fed, Die cut or Continuous direct thermal labels with or without black mark, Tag stock
-
Media Width: 0.79 inches (20 mm) – 4.65 inches (118 mm)
-
Media Roll Diameter: 127 mm max
-
Media Thickness: 76.2 μm ~ 177.8 μm
-
Core Diameter: 0.5 inch (12.7 mm), 1 inch (25.4 mm), 1.5 inches (38.1 mm)
-
Ribbon Type: Wax, Resin/Wax, Resin
-
Ribbon Length: 100 m
Sensors, Power & Memory
-
Sensors: Gap Sensor Transmissive (Fixed), Black Mark Sensor Reflective (Adjustable, Half-Range), Head-Up Sensor, Ribbon End Sensor, Paper Out Sensor
-
Button & Indicator: Feed Button, LED Indicator Light (Three colors)
-
Power Adapter Input: AC 100 ~ 240V, 50/60 Hz
-
Power Adapter Output: DC 24V, 2.5A
-
Memory: RAM 32 MB, ROM 16 MB
-
Reliability (TPH): 50 km
-
Software Driver: HPRT Driver (Windows XP, Vista, 7, 8, 10, Linux, Mac)
Options and Accessories
-
External 8-inch Label Roll Holder
-
Cutter Module (G4GC, Black)
-
Peeler Module (G4P, Black)
Physical Characteristics & Box Contents
-
Dimensions: 240 (L) × 225 (W) × 171 (H) mm
-
Empty Weight: 2.26 kg (Product Weight listed as 2.25 kg)
-
Output Type: Monochrome / Black and White
-
Functions: Print Only
-
Number of USB Ports: 1
-
Set Includes / What's In The Box: HT100 / 4" Thermal Transfer Label Printer (1 piece)
