HT100/ 4" Thermal transfer Label Printer

HT100 / 4" Thermal Transfer Label Printer — Product Overview & Specifications

Technical Specifications

• Model Name / Number: HT100 / 4" Thermal Transfer Label Printer

• Printing Method: Direct Thermal / Thermal Transfer

• Resolution: 203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)

• Printing Speed: 2 ips ~ 5 ips (at 203 dpi) / 2 ips ~ 4 ips (at 300 dpi)

• Printing Width: 20 mm ~ 108 mm (203 dpi) / 20 mm ~ 106 mm (300 dpi)

• Programming Language: TSPL, ZPL

• Printing Length: 15 mm ~ 1200 mm

• Interface Standard: USB Type-B, Serial Port, Ethernet (Ethernet Cable included)

Barcode Support

• Linear Barcodes: Code 39, Code 93, Code 128UCC, Code 128, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, UCC/EAN-128, UPC-A, UPC-E, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11

• 2D Barcodes: QR Code, PDF417, Data Matrix, Aztec

Media & Ribbon Specifications

• Media Type: Roll-fed or Fan-fed, Die cut or Continuous direct thermal labels with or without black mark, Tag stock

• Media Width: 0.79 inches (20 mm) – 4.65 inches (118 mm)

• Media Roll Diameter: 127 mm max

• Media Thickness: 76.2 $\mu m$ ~ 177.8 $\mu m$

• Core Diameter: 0.5 inch (12.7 mm), 1 inch (25.4 mm), 1.5 inches (38.1 mm)

• Ribbon Type: Wax, Resin/Wax, Resin

• Ribbon Length: 100 m

Sensors, Power & Memory

• Sensors: Gap Sensor Transmissive (Fixed), Black Mark Sensor Reflective (Adjustable, Half-Range), Head-Up Sensor, Ribbon End Sensor, Paper Out Sensor

• Button & Indicator: Feed Button, LED Indicator Light (Three colors)

• Power Adapter Input: AC 100 ~ 240V, 50/60 Hz

• Power Adapter Output: DC 24V, 2.5A

• Memory: RAM 32 MB, ROM 16 MB

• Reliability (TPH): 50 km

• Software Driver: HPRT Driver (Windows XP, Vista, 7, 8, 10, Linux, Mac)

Options and Accessories

• External 8-inch Label Roll Holder

• Cutter Module (G4GC, Black)

• Peeler Module (G4P, Black)

Physical Characteristics & Box Contents

• Dimensions: 240 (L) $\times$ 225 (W) $\times$ 171 (H) mm

• Empty Weight: 2.26 kg (Product Weight listed as 2.25 kg)

• Output Type: Monochrome / Black and White

• Functions: Print Only

• Number of USB Ports: 1

• Set Includes / What's In The Box: HT100 / 4" Thermal Transfer Label Printer (1 piece)
